For: 1/10 1/12 RC Car

Motor Limited > 4.5T

Material: Metal

Color: Black

Polar Reverse Protection

Internal Capacitor

Detachable on/off switch, ESC is always on when on/off switch disconnected

Detachable receiver, ESC come with 200mm wire, optional 105mm and 300mm BEC wire available

New CPU, Newly Design Circuit Board and Lower IR MOSFET

Brushless System

32 bit Processor

Multiple Adjustable Parameters by an optional Bluconn module via Android / iOS smart phone or by an optional program card

Specification:

BEC : 8A 6V / 7.2V

Peak Current 760A

Continuous Current 160A

Motor limit 3.5T

Motor Type: Brushless sensored 540 size Motor

Voltage input : DC 3.7V – 4.4V

Dimensions : 30.54(L) x 34(W) x 13.75(H) mm

Weight : 29.3g excluding wires
